Revit MEP Component Tutorial

Creating MEP components in Revit is probably one of the most complicated tasks as you not only have to worry about the visual aspects of the geometry, but also have to be mindful of the functional characteristics. Depending on the type, mechanical, electrical, and plumbing components need to take into account properties such as system types, flow, pressure, pressure loss, voltage, electrical panel, and so on. Aside from the parameters, you also need to create integrations between the component and the system it connects to. This brief tutorial will explain the process.
